| Model | Duty Load (KG) | Roping | Gear Center | Speed | Resio | Motor Details | RPM | Drum Dia | Brake Details | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| HP | KW | Pole | |||||||||
| VD-1 | 100 | 2:1 | 2.5” | 0.15 to 0.30 | 31:1 | 1.5 | 1.1 | 6 | 960 | 245 / 350mm | 190V DC / 415 V AC |
| VD-2 | 250 | 2:1 | 3” | 0.15 to 0.30 | 31:1 | 2 | 1.5 | 6 | 960 | 245 / 350mm | 190V DC / 415 V AC |
| VD-3 | 400 | 2:1 | 3” | 0.15 to 0.30 | 31:1 | 3 | 2.2 | 6 | 960 | 245 / 350mm | 190V DC / 415 V AC |
