| Model | Duty Load (KG) | Roping | Gear Center | Speed | Resio | Motor Details | RPM | Drum Dia | Brake Details | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| HP | KW | Pole | |||||||||
| VD-140T | 2500 | 2:1/2:2 | 140 | 0.15 to 0.30 | 60:1 | 5 | 3.7 | 6 | 960 | 245/ 350mm | 190V DC |
| ----- | 3000 | 2:1/2:2 | ----- | 0.15 to 0.30 | 60:1 | 7.5 | 5.6 | 6 | 960 | 245/ 350mm | 190V DC |
| VD-160T | 3000 | 2:1/2:2 | 160 | 0.15 to 0.30 | 60:1 | 7.5 | 5.6 | 6 | 960 | 245/ 350mm | 190V DC |
| ----- | 4000 | 2:1/2:2 | ----- | 0.15 to 0.30 | 60:1 | 10 | 7.5 | 6 | 960 | 245/ 350mm | 190V DC |
| VD-180T | 5000 | 2:1/2:2 | 180 | 0.15 to 0.30 | 60:1 | 10 | 7.5 | 6 | 960 | 245/ 350mm | 190V DC |
